Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | Leadfree Defin | Not relevant for lead free process |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | RoHSELV Compliance | RoHS compliant, ELV compliant |
| UL Flammability Rating | UL 94V-2 | Material Flammability Rating | UL 94V-2 |
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Current Rating (Max) | 13 A | Voltage - Supply (Min) | 250VAC |
| Connector - Voltage Input | Commercial Pin and Socket | ||
Mechanical
| Color | Natural | Depth | 27.94 mm |
| Pitch | 6.35 mm | Width | 8.89 |
| Length | 28.24 | Sealed | Not Sealed |
| Lock Type | Detent Lock | Packaging | Bulk |
| Contact Type | Male or Female | Housing Color | Natural |
| Mounting Type | Straight | Connector Type | Plug |
| Fastening Type | Detent Lock | Number of Rows | 1 |
| Package / Case | Plug | Housing Material | Nylon |
| Length - Overall | 6.35 [0.250] | Package Quantity | One Piece Housing |
| Panel Mount Type | 不带 | Number of Contacts | 4 |
| Contact Termination | Crimp | Number of Positions | 4 |
| Compatible Shell Size | 母端护套 | Contact Layout, Typical | In-Line |
| Contact Finish Thickness | 2.36 [0.093] | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Series | Commercial Pin and Socket |
| Product Type | Housing | Number of Circuits | 4 |
Environmental
| Operating Temperature | -55 – 105 °C [ -67 – 221 °F ] | ||
