Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 300 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | Approval Agency | :CSA, UL, VDE |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage - Test | :1500V | Voltage Rating | 600 V |
| Voltage - Supply | 600 | Current Rating (Max) | 9.5 A |
| Current - Max/Contact | :10.5A | Insulation Resistance | :100Mohm |
| Connector - Voltage Input | Mini-Universal MATE-N-LOK 2 | ||
Mechanical
| Color | White | Depth | 23.75mm |
| Pitch | 4.14 mm | Width | 17.25mm |
| Length | 31.12mm | Weight | 0.001001 |
| Lock Type | Latch | Packaging | Bulk |
| Row Spacing | 0.163" (4.14mm) | Contact Type | Male or Female |
| Mounting Type | Straight | Connector Type | Plug |
| Fastening Type | Latch Lock | Mounting Style | Free Hanging |
| Number of Rows | 2 | Housing Material | Nylon |
| Package Quantity | One Piece Housing | Primary Material | Connector |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Color - Connectors | :White | Mating Orientation | In-Line |
| Number of Contacts | 12 | Contact Termination | Crimp |
| Number of Positions | 12 | Center Contact Material | 4.14 x 4.14 [.163 x .163] |
| Contact Layout, Typical | Double-Row | Contact Finish Thickness | 0.99 [0.039] |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Series | MATE-N-LOK |
| Manufacturer | MATE-N-LOK | Product Type | Housing |
| Number of Circuits | 12 | For Use With/Related Products | Centerline Soft Shell Pin & Socket Connector |
Environmental
| Operating Temperature | :65°C | ||
Documents & Media
