Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Standard Number	CSA LR7189, UL E28476
Material Flammability Rating	UL 94 V-0

Current Rating (Max)	3 A	Insulation Resistance	5000 MOhms
Voltage - Protection Rating (VPR)	750 Vrms

Color	Black	Depth	4.87 mm
Pitch	2.54 mm	Height	10.36 mm
Base Type	不带	Lock Type	不带
Packaging	Bulk	Body Color	黑色
Lead Style	正方形	Stabilizer	不带
Row Spacing	0.100" (2.54mm)	Termination	Solder
Contact Type	Male Pin	1st Connector	否
Housing Color	Black	Mounting Type	Through Hole
Connector Type	Header, Unshrouded	Contact Finish	Gold Over Nickel
Mounting Style	Through Hole	Number of Rows	2
Insert Material	磷青铜	Contact Material	Phosphor Bronze
Housing Material	Thermoplastic	Length - Overall	19.91 mm
Package Quantity	100	Panel Mount Type	通孔
Termination Style	Through Hole	1st Connector Type	不带罩
1st Contact Gender	Pin (Male)	Diameter - Outside	.64 mm [ .025 in ]
Number of Contacts	16	Termination Finish	不带
Number of Positions	16	Length - Post (Mating)	8.08 mm
Mounting Hole Diameter	不带	Contact Length - Mating	0.318" (8.08mm)
Termination Post Length	3.18 mm	Contact Finish Thickness	30µin (0.76µm)
Static Discharge Shielding	不带	1st Connector Mounting Feature	否

Seal Rating	不带	Operating Temperature	- 65 C to + 105 C
Thermal Resistance of Package	1.397 mm [ .055 in ]	Operating Temperature - Junction	否

87215-5
