9-1393243-2
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | RT425615 | Product Category | General Purpose Relays |
| Standard Package | Bulk | Factory Pack Quantity | 20 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Coil Type | Monostable | Coil Power | 0.76 VA |
| Power - Max | .76 | Coil Current | 6.6mA |
| Isolation Type | 5000V rms | Voltage - Core | 4000 |
| Voltage Rating | 250 | Coil Resistance | 8.1 KOhm |
| Current - Surge | 8 | Voltage - Supply | 115 V |
| Switching Voltage | 400VAC - Max | Power - Peak Pulse | 2 kVA |
| Vgs(th) (Max) @ Id | 17.3 VAC | Connector Impedance | 2 Form C (CO) |
| Current - Switching | 8 A | Current - Trip (It) | 15 |
| Current Rating (Max) | 15 A | Frequency - Output 1 | 单稳态、交流 |
| Power - Output Surge | 2000 VA | Current Rating (Amps) | 5 – 10, 16 |
| Insulation Resistance | 10 mm [ .394 in ] | Voltage - Input (Min) | 400 V |
| Voltage - Switching AC | 400V 交流 | Power - Average Forward | 0.75 VA |
| Vce(on) (Max) @ Vge, Ic | 86.3 VAC | Contact Rating (Current) | 8A |
| Current - Peak Pulse (8/20us) | 8 A | Current - Discharge (Max) (8/20uS) | 8 |
| Voltage - Anode - Cathode (Vak)(Max) | 400 | ||
Mechanical
| Depth | 12.7mm | Width | 12.7 mm |
| Height | 15.7 mm | Length | 29 mm |
| Weight | 13 g [ .459 oz ] | Packaging | Tube |
| Insulation | 继电器基极 PTI250 的跟踪指数 | Contact Form | 2 Form C (DPDT-BM) |
| Height (Max) | 15 – 16 | Mounting Type | Through Hole |
| Terminal Type | Through Hole | Mounting Style | Through Hole |
| Contact Material | Silver Nickel 90/10/Gold Plated | Size / Dimension | 29 x 12.7 x 15.7mm |
| Insulation Height | 8 | Termination Style | PC Pin |
| Number of Contacts | 2 | Primary Winding(s) | UL 线圈绝缘类 F |
| Insulation Diameter | 10 mm [ .394 in ] | Insulation Material | 5kV rms |
| Width / Cross Section | 12 – 16 | Contact Layout, Typical | DPDT |
| 1st Connector Mounting Type | 印刷电路板, 插座 | ||
Product Info
| Type | Power Relay | Series | RT2 |
| Features | Insulation - Class F, Sealed - Flux Protection | Function | Y |
| Relay Type | General Purpose | Application | 电源 |
| Application Specifics | Power | ||
Environmental
| Ingress Protection | RTII | Operating Temperature | -40 to 70 °C |
| Initial Dielectric Strength | 1000 | ||
