Business
| Part # Aliases | 2-1393186 2-1393186-0 | Product Category | General Purpose Relays |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant By Exemption | Tariff No | 85364110 |
Electrical
| Coil Type | Monostable | Coil Power | 360 mW |
| Range deg/s | :TE - T7N Series | Coil Current | 7.5mA |
| Release Time | 5ms | Coil Resistance | 6400 Ohms |
| Current - Output | :10A | Voltage - Supply | 48 V |
| Switching Voltage | 240VAC, 28VDC - Max | Vgs(th) (Max) @ Id | 4.8 VDC |
| Power - Output Surge | 2.5 kVA | Contact Voltage (Max) | :250V |
| Power - Average Forward | 360 mW | Vce(on) (Max) @ Vge, Ic | 33.6 VDC |
| Contact Rating (Current) | 10A | ||
Mechanical
| Depth | 16.5mm | Width | 16 mm |
| Height | 16.4 mm | Length | 22 mm |
| Weight | 0.009 | Packaging | Bulk |
| Contact Form | 1 Form C (SPDT-BM) | Mounting Type | Through Hole |
| Terminal Type | Through Hole | Mounting Style | PCB |
| Contact Material | Silver Cadmium Oxide | Termination Style | PC Pin |
| Contact Termination | PCB | Contact Layout, Typical | SPDT |
Product Info
| Series | T7N | Features | Insulation - Class F, Sealed - Fully |
| Relay Type | General Purpose | Application Specifics | Power |
Environmental
| Operate Time | 9ms | Mechanical Life | Obsolete |
| Operating Temperature | -40°C ~ 85°C | ||
