LM22673MRE-5.0/NOPB
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | Simple Switcher | Standard Package | Tape & Reel |
| Factory Pack Quantity | 250 | Standard Package Name | HSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | ||
Electrical
| Output | 1 | PWM Type | Voltage Mode |
| Duty Cycle | 90 | Efficiency | 90(Min) % |
| Output Type | Fixed | Converter Type | Step Down |
| Regulator Type | 是 | Voltage Rating | 5 V |
| Delay Time - ON | Adjustable | Load Regulation | 90 % |
| Current - Output | 3 A | Current - Supply | 3.4 mA |
| Voltage - Supply | 4.5 to 42 V | Number of Outputs | 1 |
| Current - Switching | 4.2 | Switching Regulator | Yes |
| Current Rating (Max) | Catalog | Must Release Voltage | Fixed |
| Frequency - Switching | 500(Typ) kHz | Synchronous Rectifier | No |
| Voltage - Input (Min) | 5V | Voltage - Output (Max) | 5 V |
| Current - Quiescent (Iq) | 3.4 | Voltage Regulation - Load | Internal |
| Accuracy - Voltmeter; Ammeter | 1.5 | ||
Mechanical
| Width | 3.9mm | Height | 1.47mm |
| Length | 4.9mm | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | 8 |
| Package / Case | 8PSOP EP | Package Cooled | PSOP |
| Length - Overall | 5(Max) | Package Quantity | HSOP EP |
| Size / Dimension | 4.9 x 3.9 x 1.47mm | Number of Positions | 8 |
| Shell Size - Insert | 1.55(Max) | Supplier Device Package | 8-SO PowerPad |
Product Info
| Type | Inverting|Step Down | Series | LM22673 |
| Features | Enable | Software | SNVS586O |
| Topology | Buck | Application | Industrial |
| Manufacturer | SIMPLE SWITCHER | Control Method | Voltage Mode |
| Development Kit | LM22673EVAL/NOPB | Functional Diagram | fbd_snvs586o.gif |
| Utilized IC / Part | View | Printed Circuit Board | 8 |
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | -40 to 125 °C |
Documents & Media
PDF Document
PDF Document
PDF Document
Online Document
Online Document
Sourcing & traceability
- Datasheet
- lm22673.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
