CC8520RHAT
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-27249-2 | Product Category | RF Transceiver |
| Standard Package | Tape & Reel | Factory Pack Quantity | 250 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
Electrical
| Data Rate | :5Mbps | Frequency | 2.4GHz |
| Modulation | :FSK | Resolution | ISM |
| Sensitivity | -83dBm | Data Interface | PCB, Surface Mount |
| Power - Output | 3.5dBm | Voltage Rating | 2.5|3.3 V |
| Data Rate (Max) | 5000 Kbps | Frequency - Max | 2483.5 MHz |
| Frequency - Min | :2.4GHz | Frequency Range | :2.4GHz to 2.4835GHz |
| Voltage - Supply | 2 V to 3.6 V | Number of Channels | 2 |
| Current - Receiving | 25mA | Current Rating (Max) | 29(Typ), 25(Typ) |
| Current - Max/Contact | 25(Typ) mA | Frequency - Operating | 2400 MHz |
| Current - Transmitting | 29mA | Voltage - Supply (Min) | 3.6 V |
Mechanical
| Width | 6.15(Max) | Weight | 0.00022 |
| Bandwidth | 2.4GHz | Packaging | Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :40 |
| Package / Case | QFN-40 | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 6.15(Max) | Package Quantity | VQFN EP |
| Antenna Connector | PCB, Surface Mount | Number of Positions | 40 |
| Shell Size - Insert | 0.95(Max) | ||
Product Info
| Series | CC8520 | Applications | :Point-to-Point Audio, Wireless High Quality Digital Audio, Wireless (USB) Headphones / Headsets |
| Printed Circuit Board | 40 | ||
Environmental
| Operating Temperature | -40 °C | ||
Documents & Media
PDF Document
PDF Document
Online Document
Online Document
Similar Parts
Sourcing & traceability
- Datasheet
- CLARK-AT Revision A 29/Aug/2013
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
