LM22670MRX-5.0/NOPB
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | SIMPLE SWITCHER | Other Names | 296-37361-1 |
| Standard Package | Tape & Reel | Factory Pack Quantity | 2500 |
Compliance
| RoHS | Lead free / RoHS Compliant | Part Status | ACTIVE |
Electrical
| Output | 1 | PWM Type | Voltage Mode |
| Duty Cycle | 90 | Efficiency | 90(Min) % |
| Output Type | Fixed | Voltage Rating | 5 V |
| Delay Time - ON | Fixed | Load Regulation | 90 % |
| Current - Output | 3 A | Current - Supply | 3.4 mA |
| Voltage - Supply | 4.5 to 42 V | Number of Outputs | 1 |
| Current - Switching | 4.2 | Current Rating (Max) | Catalog |
| Must Release Voltage | Fixed | Frequency - Switching | 500(Typ) kHz |
| Synchronous Rectifier | No | Voltage - Input (Min) | 5V |
| Current - Quiescent (Iq) | 3.4 | Voltage Regulation - Load | Internal |
| Accuracy - Voltmeter; Ammeter | 1.5 | ||
Mechanical
| Packaging | Tape & Reel (TR) | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8PSOP EP |
| Package Quantity | 2500 | Supplier Device Package | 8-SO PowerPad |
Product Info
| Type | Step Down | Series | LM22670 |
| Features | Enable | Software | SNVS584P |
| Topology | Buck | Application | Industrial |
| Manufacturer | SIMPLE SWITCHER | Control Method | Voltage Mode |
| Functional Diagram | fbd_snvs584p.gif | Utilized IC / Part | View |
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | -40 to 125 °C |
