SN74LVT245BPW
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Standard Transceiver | Product Category | Bus Transceivers |
| Standard Package | Rail / Tube | Factory Pack Quantity | 70 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Voltage | 3.3 | Data Rate | Bi-Directional |
| Input Type | TTL/CMOS | Logic Type | LVT |
| Output Type | 3-State | Number of I/O | 5 V |
| Output Signal | LVTTL | Number of Bits | 8 |
| Voltage Rating | 3.3 V | Current - Output | 0.19 mA |
| Current - Supply | 190 uA | Voltage - Output | LVTTL |
| Voltage - Supply | 2.7 V ~ 3.6 V | Number of Channels | 8 |
| Number of Elements | 1 | Current Rating (Max) | Catalog |
| Frequency - Output 1 | 160 | Schmitt Trigger Input | No |
| Voltage - Supply (Min) | 2.7 V | Input Logic Level - Low | LVTTL |
| Propagation Delay (Max) | 50pF | Delay Time - Propagation | 2.3 ns |
| Input Logic Level - High | LVTTL | Current - Quiescent (Max) | 5 |
| Current - Output 1 (Range) | 64mA | Current - Output 2 (Range) | -32mA |
| Current - Output High, Low | 32mA, 64mA | Number of Bits per Element | 8 |
| Current - Output Source/Sink | -32/64 | Propagation Delay tpLH / tpHL (Max) | 3.5 |
| Common Mode Transient Immunity (Min) | Commercial | ||
Mechanical
| Width | 4.4mm | Height | 1.15mm |
| Length | 6.5mm | Weight | 0.002716 oz |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | 20 | Package / Case | 20TSSOP |
| Package Cooled | TSSOP | Length - Overall | 6.6(Max) |
| Package Quantity | TSSOP | Size / Dimension | 6.5 x 4.4 x 1.15mm |
| Number of Positions | 20 | Shell Size - Insert | 1.05(Max) |
| Supplier Device Package | 20-TSSOP | Pulse Width Distortion (Max) | 2.3 ns @ 3.3 V |
Product Info
| Series | SN74LVT245B | Process | BiCMOS |
| Function | Bus Transceiver | Polarity | Non-Inverting |
| Software | SCES004H | Technology | BiCMOS |
| Manufacturer | Texas Instruments | Number of Circuits | 8 |
| RF Family/Standard | LVT | Utilized IC / Part | View |
| Printed Circuit Board | 20 | Number of Inputs and Type | 1 Low/High |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- SN74LVT245B
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
