TLV320AIC3101IRHBT
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio CODECs | Other Names | 296-21969-2 |
| Product Category | Interface - CODECs | Standard Package | Tape & Reel |
| Factory Pack Quantity | 250 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Output | 2 | DAC Type | 2 |
| Interface | Serial (2-Wire, I2C) | S/N Ratio | 102 |
| Output Fan | Yes | Resolution | 24 bit |
| Input Range | 2 | Sigma Delta | Yes |
| Input Signal | L R I2S DSP TDM | Output Power | 0.5 W |
| Power - Input | 单 | Data Interface | PCM Audio Interface |
| Spectral Range | -89 | Voltage Rating | 1.1|1.525|2.7 |
| Data Rate (Max) | 96 kSPs | Number of DAC's | 6 |
| Voltage - Supply | 1.8|3.3 V | Distortion Rating | -95 |
| Number of Outputs | 2 | Power Supply Type | Analog|Digital |
| Resolution (Bits) | 24 Bit | Number of Channels | 2ADC /2 DAC |
| Power - Peak Pulse | 0.5 | Sampling Frequency | 96 ksps |
| Current Rating (Max) | Catalog | Number of ADCs / DACs | 4 |
| Voltage - Supply (Min) | 1.1/1.525/2.7 V | Power - Average Forward | 14 |
| Voltage - Supply, Analog | 2.7 V ~ 3.6 V | Voltage - Supply, Digital | 1.65 V ~ 1.95 V |
| Sampling Rate (Per Second) | 96 KSPS | S/N Ratio, ADCs / DACs (db) Typ | 92 / 102 |
| Dynamic Range, ADCs / DACs (db) Typ | 93 / 97 | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 5.15mm | Height | 0.95mm |
| Length | 5.15mm | Weight | 0.002547 oz |
| Packaging | Tape and Reel | Lead Style | No Lead |
| Mounting Type | Surface Mount | Connector Type | PCM Audio Interface |
| Diameter - Bit | 24 b | Mounting Style | SMD/SMT |
| Number of Pins | 32 | Package / Case | 32VQFN EP |
| Package Cooled | VQFN EP | Length - Overall | 5.15(Max) |
| Package Quantity | VQFN EP | Size / Dimension | 5.15 x 5.15 x 0.95mm |
| Number of Positions | 32 | Shell Size - Insert | 0.95(Max) |
| Supplier Device Package | 32-VQFN (5x5) | ||
Product Info
| Type | General Purpose | Series | TLV320AIC3101 |
| Features | LP Bypass Notch Filtering 3D EQ Matrix Mixing PLL Stereo Speaker Amplifier | Function | Y |
| Software | SLAS520E | Manufacturer | Texas Instruments |
| Amplifier Type | Class-AB | Translator Type | 通用 |
| Control Interface | I2C | Functional Diagram | fbd_slas520e.gif |
| Utilized IC / Part | View | Other Specifications | Yes |
| Output Configuration | Surface Mount | Printed Circuit Board | 32 |
| Number of A/D Converters | 2 | Number of Inputs and Type | 6 / 6 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
| Operating Temperature - Junction | 85C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- TLV320AIC3101
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
