TLV320AIC3106IRGZR
| Manufacturer | |
| Description | Audio Codec 2ADC / 2DAC 24-Bit 48-Pin VQFN EP T/R IC STER AUD CODEC 32 BIT 48-VQFN Low-Power Stereo CODEC with 10 Inputs, 7 Outputs, HP Amplifier and Enhanced Digital Effects Interface - CODECs Lo-Pwr Stereo CODEC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio CODECs | Other Names | 296-22705-2 |
| Standard Package | Tape & Reel | Factory Pack Quantity | 2500 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | ||
Electrical
| DAC Type | 2 | Interface | Serial (2-Wire, I2C, SPI) |
| S/N Ratio | 102 | Output Fan | Yes |
| Resolution | 24 bit | Sigma Delta | Yes |
| Input Signal | L R I2S DSP TDM | Data Interface | PCM Audio Interface |
| Spectral Range | -88 | Voltage Rating | 2.7 |
| Data Rate (Max) | 96 kHz | Number of DAC's | 7 |
| Voltage - Supply | 3.3 V | Distortion Rating | -94 |
| Power Supply Type | Analog|Digital | Resolution (Bits) | 24 Bit |
| Number of Channels | 2ADC /2 DAC | Sampling Frequency | 96 ksps |
| Current Rating (Max) | Catalog | Number of ADCs / DACs | 6 |
| Voltage - Supply (Min) | 3.6 | Power - Average Forward | 14 |
| Voltage - Supply, Analog | 2.7 V ~ 3.6 V | Voltage - Supply, Digital | 1.65 V ~ 1.95 V |
| S/N Ratio, ADCs / DACs (db) Typ | 92 / 102 | Dynamic Range, ADCs / DACs (db) Typ | 91 / 92 |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 7.15(Max) | Height | 0.9 mm |
| Length | 7 mm | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 48VQFN EP |
| Length - Overall | 7.15(Max) | Package Quantity | VQFN EP |
| Number of Positions | 48 | Shell Size - Insert | 0.95(Max) |
| Supplier Device Package | 48-VQFN (7x7) | ||
Product Info
| Type | General Purpose | Series | TLV320AIC3106 |
| Features | 3D EQ Matrix Mixing PLL Alt Audio Int. HS detect | Software | SLAS509F |
| Manufacturer | Texas Instruments | Control Interface | SPI I2C |
| Functional Diagram | fbd_slas509f.gif | Utilized IC / Part | View |
| Printed Circuit Board | 48 | Number of Inputs and Type | 10 / 7 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
