TLV320AIC3262IYZFT
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-30457-1 | Product Category | Interface - CODECs |
| Standard Package | 250 | Factory Pack Quantity | 250 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| DAC Type | 2 | Coil Type | Stereo Audio |
| Interface | Serial (I2C, SPI) | S/N Ratio | 101 |
| Output Fan | Yes | Resolution | 12 bit |
| Output Type | Yes | Sigma Delta | Yes |
| Input Signal | I2S TDM DSP L&R PCM | Data Interface | I²C, SPI |
| Voltage Rating | 1.8 V | Number of DAC's | 2 |
| Number of Inputs | :8 | Voltage - Supply | 2.7 V to 5.5 V |
| Power Supply Type | Analog|Digital | Resolution (Bits) | 32 b |
| Number of Channels | 2 (ADC), 4 (DAC) | Power - Peak Pulse | 2 |
| Sampling Frequency | 48kHz | Current Rating (Max) | Catalog |
| Number of ADCs / DACs | 2 | Voltage - Supply (Min) | 1.95/3.6/5.5 V |
| Power - Average Forward | 5 | Voltage - Supply, Analog | 1.5 V ~ 1.95 V |
| Voltage - Supply, Digital | 1.26 V ~ 1.95 V | Sampling Rate (Per Second) | 192 KSPS |
| S/N Ratio, ADCs / DACs (db) Typ | 93 / 101 | Dynamic Range, ADCs / DACs (db) Typ | 93 / 101 |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 4.839mm | Height | 0.275mm |
| Length | 4.839mm | Weight | 0.000833 |
| Packaging | Tape and Reel | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :81 |
| Package / Case | 81-UFBGA, DSBGA | Package Cooled | WCSP |
| Material Finish | :- | Length - Overall | 4.84(Max) |
| Package Quantity | WCSP | Size / Dimension | 4.839 x 4.839 x 0.275mm |
| Number of Positions | 81 | Shell Size - Insert | 0.28(Max) |
| Supplier Device Package | 81-DSBGA (4.81x4.81) | ||
Product Info
| Type | PCM | Series | TLV320AIC3262 |
| Features | miniDSP | Software | SLAS679 |
| Base Unit | :320 | Amplifier Type | Class-D |
| Pattern Number | Y | Control Interface | I2C SPI |
| Functional Diagram | fbd_slas679.gif | Utilized IC / Part | View |
| Printed Circuit Board | 81 | Number of Inputs and Type | 8 / 7 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
| Operating Temperature - Junction | 85C | ||
Documents & Media
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- TLV320AIC3262
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
