UCC25230DRMT
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-29900-2 | Product Category | Voltage Regulators - Switching Regulators |
| Standard Package | 250 | Factory Pack Quantity | 250 |
| Standard Package Name | SON | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| PWM Type | Voltage Mode | Isolation | Isolated |
| Duty Cycle | 90 | Output Type | Adjustable |
| Voltage Rating | 8.46 V to 9.54 V | Line Regulation | 40mV |
| Load Regulation | 40mV | Current - Output | 200mA |
| Number of Outputs | 1 | Regulator Topology | Step Down |
| Switching Regulator | Yes | Frequency - Switching | 380kHz |
| Synchronous Rectifier | Yes | Voltage - Input (Min) | 3.3 V ~ 48 V |
| DC Voltage - Input (Min) | 12 V | ||
Mechanical
| Width | 4 | Weight | 0.012 |
| Packaging | Tape and Reel | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :8 | Package / Case | 8-VDFN Exposed Pad |
| Package Cooled | VSON EP | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 4 | Package Quantity | VSON EP |
| Number of Positions | 8 | Shell Size - Insert | 0.9 |
| Supplier Device Package | 8-VSON (4x4) | ||
Product Info
| Type | Step Down | Series | UCC25230 |
| DELETED | Compliant | Software | SLUSAQ6B |
| Topology | Buck Forward Flyback Synchronous Buck | Base Unit | :25230 |
| Pattern Number | Y | Functional Diagram | alt_slusaq6b.gif |
| Utilized IC / Part | View | Printed Circuit Board | 8 |
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | -40°C ~ 125°C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- UCC25230
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
