9512260000
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | WAD 20 GE | Standard Package | Bag |
Compliance
| RoHS | Lead free / RoHS Compliant | IEC Standard | 27-14-11-92 |
| Standard Number | 30-21-18-11 | Material Flammability Rating | V-2 |
Electrical
| Frequency | 27-14-11-33 | ||
Mechanical
| Color | Yellow | Depth | 13.43 mm |
| Pitch | 18 mm | Width | 18 mm |
| Height | 48.5 mm | Weight | 2.323 g |
| Material | PA 66 | Step Angle | 9512260000_32165_WAD_20_STP.stp |
| Depth (Inches) | 0.529 inch | Fastening Type | Snap-on |
| Mounting Rails | none | Width (Inches) | 0.709 inch |
| Height (Inches) | 1.909 inch | Color - Connectors | Yellow |
Product Info
| Type | Cover | Legend | Danger Sign |
| ETIM 6*0 | EC002848 | File Type | 32165_WAD_20_GE_DXF.dxf |
| GTIN (EAN) | 4008190403942 | Engineering Data | EPLAN |
| Firmware Version | For the terminals | Installation Type | Direct mounting |
| RF Family/Standard | 9512260000 | Other Specifications | No |
| For Use With/Related Products | W Series | ||
Environmental
| ET (Volt-Time) | EC000897 | Ingress Protection | 27-14-11-45 |
| Operating Temperature | -50 °C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 9512260000
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
