68611414122
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 732-2006-2 | Standard Package | 1,500 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85366990 | ||
Electrical
| Voltage Rating | 125V | Current Rating (Max) | 1A |
Mechanical
| Pitch | 0.039" (1.00mm) | Weight | 0.00001 |
| Packaging | Tape & Reel (TR) | Termination | Solder |
| Lead Spacing | :1mm | Mounting Type | Surface Mount, Right Angle |
| Cable End Type | Tapered | Connector Type | Top Contacts |
| Contact Finish | Tin | Number of Rows | 1 |
| Locking Feature | Slide Lock | Contact Material | Phosphor Bronze |
| Contact Position | :Bottom | Housing Material | Polyphenylene Sulfide (PPS) |
| FFC, FCB Thickness | 0.30mm | Height Above Board | 0.116" (2.95mm) |
| Number of Contacts | 14 | Contact Termination | :Surface Mount Right Angle |
| Number of Positions | 14 | Contact Finish Thickness | 100µin (2.54µm) |
Product Info
| Type | Wire to Board | Gender | :Plug |
| Series | 686 | Features | Solder Retention, Zero Insertion Force (ZIF) |
Environmental
| Operating Temperature | -25°C ~ 85°C | ||
