68612214422
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 732-3510-2 | Standard Package | 1,500 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | ||
Electrical
| Voltage Rating | 125V | Current Rating (Max) | 1A |
Mechanical
| Pitch | 0.039" (1.00mm) | Weight | 0.001 |
| Packaging | Tape & Reel (TR) | Termination | Solder |
| Mounting Type | Surface Mount, Right Angle | Cable End Type | Tapered |
| Connector Type | Bottom Contacts | Contact Finish | Tin |
| Number of Rows | 1 | Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze | Contact Position | :Bottom |
| Housing Material | Polyphenylene Sulfide (PPS) | FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.118" (3.00mm) | Number of Contacts | 22 |
| Contact Termination | :Surface Mount Right Angle | Number of Positions | 22 |
| Contact Finish Thickness | 100µin (2.54µm) | ||
Product Info
| Type | Wire to Board | Gender | :Socket |
| Series | 686 | Features | Solder Retention, Zero Insertion Force (ZIF) |
Environmental
| Operating Temperature | -25°C ~ 85°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 6861xx14422 Drawing
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
