68714014022
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 732-3519-2 | Standard Package | 2,000 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Material Flammability Rating | UL 94 V-0 |
Electrical
| Voltage Rating | 50V | Current Rating (Max) | 0.5A |
| Insulation Resistance | 100 MOhms | ||
Mechanical
| Pitch | 0.020" (0.50mm) | Weight | 0.001 |
| Packaging | Tape & Reel (TR) | Termination | Solder |
| Mounting Type | Surface Mount, Right Angle | Cable End Type | Tapered |
| Connector Type | Top Contacts | Contact Finish | Tin |
| Number of Rows | 1 | Locking Feature | Flip Lock |
| Contact Material | Phosphor Bronze | Contact Position | :Top |
| Housing Material | Liquid Crystal Polymer (LCP) | FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.079" (2.00mm) | Number of Contacts | 40 |
| Contact Termination | :Surface Mount Right Angle | Number of Positions | 40 |
| Switch Actuation Level | ZIF | Contact Layout, Typical | Top Contact |
| Contact Finish Thickness | 100µin (2.54µm) | ||
Product Info
| Type | Wire to Board | Gender | :Socket |
| Series | 687 | Features | Zero Insertion Force (ZIF) |
| Product Type | Board Mount | ||
Environmental
| Temperature Range | - 25 C to + 85 C | Operating Temperature | -25°C ~ 85°C |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 6871xx14022 Drawing
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
