Business
| Product | Ferrite Chip Beads | Other Names | 732-4484-2 |
| Standard Package | 4,000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85049011 | ||
Electrical
| Impedance | 1 kOhms | Tolerance | ±25% |
| Filter Type | Differential Mode - Single | Test Frequency | 100 MHz |
| Current Rating - DC | :200mA | DC Resistance (DCR) | 600 mOhm Max |
| Current Rating (Max) | 200mA | Impedance @ Frequency | 1 kOhm @ 100MHz |
| DC Resistance (DCR) (Max) | :0.6ohm | Resistance - Initial (Ri) (Min) | 600mΩ |
Mechanical
| Depth | 0.8mm | Width | 0.8 mm |
| Height | 0.8mm | Length | 1.6mm |
| Weight | 0.0001 | Packaging | Tape & Reel (TR) |
| Height (Max) | 0.039" (1.00mm) | Core Material | Ferrite |
| Mounting Type | Surface Mount | Package / Case | 0603 (1608 Metric) |
| Mounting Feature | :SMD | Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
| Termination Style | SMD/SMT | ||
Product Info
| Series | WE-CBF | ||
Environmental
| Operating Temperature | +125°C | ||
Documents & Media
Online Document
Online Document
Online Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 742792zzz.stp
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
