744042001
| Manufacturer | |
| Description | Fixed Inductors 2700mA, 1uH DCR Max=0.03, +/-30% INDUCTOR POWER 1.0UH 2.7A SMD Inductor SMD WE-TPC 4818 1.0uH 2.6A Fixed Inductors WE-TPC Inductor 1uH 100kHz CHOKE, SMD 1.0UH, 2.7A Wurth 铁氧体芯材 绕线贴片电感器, 1 μH ±30%, 2.7A Idc |
| Category |
Business
| Product | SMD Power Inductors | Other Names | 732-1016-2 |
| Product Category | Fixed Inductors | Standard Package | 800 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85045095 | ||
Electrical
| Core Type | :Shielded | Tolerance | 30 % |
| Inductance | 1 uH | Range deg/s | :WURTH ELEKTRONIK - WE-TPC Series |
| Test Frequency | 100 kHz | Inductance Range | :± 30% |
| DC Resistance (DCR) | 30 mOhm Max | Current Rating (Max) | 2.7 A |
| DC Resistance (DCR) (Max) | :0.03ohm | Frequency - Self Resonant | 177 MHz |
| Current - Saturation (Isat) | :2.6A | Current Saturation - Series | 2.6A |
| Resistance - Initial (Ri) (Min) | 0.03 Ohms | Current - On State (It (RMS)) (Max) | :2.7A |
Mechanical
| Width | 4.8 mm | Weight | 0.005820 oz |
| Packaging | Reel | Shielding | Shielded |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | 1.8 mm | Material - Core | Ferrite |
| Size / Dimension | 4.8 mm W x 4.8 mm L x 1.8 mm H | Termination Style | SMD/SMT |
| Dimensions - Overall | :4.8mm x 4.8mm x 1.8mm | Height - Seated (Max) | 0.078" (2.00mm) |
Product Info
| Type | SMD Shielded Tiny Power Inductor | Series | WE-TPC |
Environmental
| Operating Temperature | - 40 C to + 125 C | ||
Documents & Media
Similar Parts
744028
Wurth Electronics
Inductor Kits & Accessories WE-TPC Design Kit Small Size KIT INDUCTOR TPC SMALL SIZES Wurth Elektronik Small Power Chokes Inductor Design Kit, 7 Pieces INDUCTORS, ASSORTMENT, SMDSMALL Wurth Elektronik 7件 电感器套件, 套件包含小功率扼流圈
LTC3589EUJ#PBF
Analog Devices, Inc.
Regulator 40-Pin QFN EP IC DC/DC CONV 8-OUTPUT 40QFN IC, DC/DC CONV, 2.25 MHz, 40QFN DC-DC converter; step up/down; Uin:2.7÷5.5V; Uout:0.75÷5V; 2.7A
LTC3589HUJ#PBF
Analog Devices, Inc.
Regulator 40-Pin QFN EP IC DC/DC CONV 8-OUTPUT 40QFN IC, DC/DC CONV, 2.25 MHz, 40QFN DC-DC converter; step up/down; Uin:2.7÷5.5V; Uout:0.75÷5V; 2.7A
LT3503EDCB#TRMPBF
Analog Devices, Inc.
Conv DC-DC Single Step Down 3.6V to 20V 6-Pin DFN EP T/R IC REG BUCK ADJ 1A 6DFN LT3503EDCB#TRMPBF, DC-DC Converter, Step Down, 2.4MHz, 6-Pin DFN IC, SW BUCK REG, 1A, 2.2MHZ, 6DFN Linear Technology 直流-直流转换器, 降压, 3.6 → 20 V输入, 2.4 MHz, 6针 DFN封装
LT3502EMS#PBF
Analog Devices, Inc.
Conv DC-DC Single Step Down 3V to 40V 10-Pin MSOP IC REG BUCK ADJ 0.5A 10MSOP LT3502EMS#PBF, DC-DC Converter, 3.3V Step Down, 1.4MHz, 10-Pin MSOP IC, SW REG, 500MA, 10MSOP DC-DC converter; step up; Uin:3÷40V; Uout:0.8÷36V; 500mA; MSOP10 Linear Technology 直流-直流转换器, 降压, 500mA, 3 → 40 V输入, 1.4 MHz, 10针 MSOP封装
LT3493EDCB#TRMPBF
Analog Devices, Inc.
Conv DC-DC Single Step Down 3.6V to 36V 6-Pin DFN EP T/R IC REG BUCK ADJ 1.2A 6DFN Sw. Regulator 1.2A 750kHz Step-Down DFN6 IC, SW REG, 1.2A, 750KHZ, 6DFN Linear Technology 降压 开关稳压器, 1.2A, 0.78 → 50 V, 815 kHz, 6针 DFN封装
LT3686HDD#PBF
Analog Devices, Inc.
Conv DC-DC Single Step Down 3.6V to 37V 10-Pin DFN EP IC REG BUCK ADJ 1.2A 10-DFN IC, PWM STEP-DOWN DC/DC CONVERTER, DFN10 BUCK, 37V, 1.2A, 10DFN
LT3502AIDC#TRMPBF
Analog Devices, Inc.
IC BUCK ADJ 0.5A 8DFN IC REG BUCK ADJ 0.5A 8DFN LT3502AIDC#TRMPBF, DC-DC Converter, 3.3V Step Down, 2.8MHz, 8-Pin DFN Conv DC-DC Single Step Down 3V to 40V 8-Pin DFN EP T/R IC, SW REG, 2.2MHZ, 500MA, 8DFN Linear Technology 直流-直流转换器, 降压, 500mA, 3 → 40 V输入, 2.8 MHz, 8针 DFN封装
LT3689EMSE-5#PBF
Analog Devices, Inc.
IC BUCK 5V 0.7A 16MSOP IC REG BUCK 5V 0.7A 16MSOP
ELLVGG1R0N
