C0603C105K4PACTU
| Category |
对参数有疑问？问 AI 助手
Business
| Product | General Type MLCCs | Other Names | 399-5090-1 |
| Part # Aliases | C0603C105K4PAC7867 | Product Category | Multilayer Ceramic Capacitors MLCC - SMD/SMT |
| Standard Package | Cut Tape | Factory Pack Quantity | 4000 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85322100 |
| Rad Hardened | No | ||
Electrical
| Voltage | 16 Vdc | Tolerance | 10 % |
| Capacitance | 1 uF | Range deg/s | :KEMET - C Series |
| Voltage Rating | 16 V | Capacitance - Input | :0603 [1608 Metric] |
| Capacitance @ Vr, F | :X5R | Dissipation Factor (DF) | 5 |
Mechanical
| Depth | 0.8 mm | Width | 0.8 mm |
| Height | 0.8 mm | Weight | 0.027 |
| Diameter | Not Required mm | Packaging | Reel |
| Termination | SMT | Construction | Flat |
| Lead Spacing | 0.7 mm | Mounting Type | Surface Mount |
| Terminal Type | :Surface Mount (SMD, SMT) | Mounting Style | Surface Mount |
| Package / Case | 0603 | Material Finish | :MSL 1 - Unlimited |
| Thickness (Max) | 0.035" (0.90mm) | Length - Overall | 1.6 mm |
| Material - Blade | Ceramic | Size / Dimension | 0.8 mm W x 1.6 mm L x 0.8 mm H |
| Termination Style | SMD/SMT | Dielectric Material | X5R |
| Shell Size - Insert | 0603(1608mm) | Mounting Hole Diameter | 0603 |
| Wire Gauge or Range - AWG | Not Required | ||
Product Info
| Type | X5R Dielectric, Commercial | Class | 2 |
| Series | C0603C | DELETED | Compliant |
| Features | HighCV | Technology | Standard |
| Applications | General Purpose | Failure Rate | Not Required |
Environmental
| Operating Temperature | -55 to 85 °C | Temperature Coefficient | X5R |
Documents & Media
Online Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- DataSheet?pn=C0603C105K4PAC7867
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
