RJHSE-3384
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Modular Jacks | Other Names | RJHSE3384 |
| Product Category | Modular Connectors / Ethernet Connectors | Standard Package | Trays |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage Rating | 125 V | Current Rating (Max) | 1.5 A |
| Insulation Resistance | 500 MOhms | Connector - Voltage Input | :- |
Mechanical
| Color | Black | Pitch | 2.03 mm |
| Weight | 0.01 | LED Color | Green - Yellow |
| Packaging | Tray | Shielding | Shielded |
| Orientation | Vertical | Termination | Solder |
| Mounting Type | Through Hole | Tab Direction | User Selectable |
| Connector Type | Jack | Contact Finish | Gold |
| Number of Rows | 1 | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Termination Style | Through Hole |
| Number of Contacts | 8 | Contact Termination | :Through Hole Vertical |
| Number of Positions | :8 | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | RJ-45 | Gender | F |
| Series | RJHSE | Features | Board Lock, Panel Stops |
| USOC Codes | RJ45 | Number of Ports | 1 |
| Performance Category | Cat 5 | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Ratings | Cat5 | Operating Temperature | -55°C ~ 85°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- Multiple Series Copper 29/Jan/2009
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
