Business
| Product | Connectors | Other Names | ACX1033 |
| Part # Aliases | 319-0029 99H4336 | Product Category | RF Connectors / Coaxial Connectors |
| Standard Package | Bag | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85366910 |
Electrical
| Frequency | 0 to 4 GHz | Impedance | 50 Ohm |
| Voltage Rating | 500V | Coupling Factor | Bayonet |
| Frequency - Max | 4GHz | ||
Mechanical
| Weight | 0.555918 oz | Packaging | Bulk |
| Cable Type | RG-174, RG-188A, RG-316, Belden 7805A | Body Finish | Nickel |
| Cable Group | RG-174, 316, LMR-100 | Orientation | Straight |
| Termination | Crimp | Body Material | Brass |
| Housing Color | Silver | Mounting Type | Panel Mount |
| Angle of Throw | Straight | Connector Type | Jack, Female Socket |
| Contact Finish | Gold | Fastening Type | Bayonet Lock |
| Housing Finish | Nickel | Connector Style | BNC |
| Connector Usage | Bayonet | Contact Material | Phosphor Bronze |
| Housing Material | Brass | Primary Material | BNC |
| Termination Style | Cable - Crimp | Shield Termination | Crimp |
| Contact Termination | Crimp | Dielectric Material | Polyoxymethylene (POM) Acetal |
| Center Contact Plating | Gold | Center Contact Material | Phosphor Bronze |
| Supplier Device Package | Bulkhead | ||
Product Info
| Type | BNC | Gender | F |
| Features | Captivated Contact | Polarity | Standard |
| Connection Type | Coaxial Cable | RF Family/Standard | BNC |
| Application Specifics | Commercial | ||
Environmental
| Mating Cycles | 500 | Operating Temperature | - 40 C to + 155 C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 112234.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
