Business
| Product | Connectors | Part # Aliases | 031-318 16R0579 51F3822 713-1088 |
| Product Category | RF Connectors / Coaxial Connectors | Standard Package | 1 |
Compliance
| RoHS | Compliant | Tariff No | 85369010 |
Electrical
| Impedance | 50 Ohm | Voltage Rating | 500V |
| Coupling Factor | Bayonet | Frequency - Max | 4GHz |
Mechanical
| Weight | 0.703998 oz | Packaging | Bulk |
| Cable Type | RG-174, RG-188, RG-316, Belden 7805 | Body Finish | Nickel |
| Cable Group | RG-174, 188A | Orientation | Straight |
| Weight (g): | 19.60000 | Body Material | Brass |
| Housing Color | Silver | Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
| Connector Type | Jack, Female Socket | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Connector Style | BNC |
| Contact Material | Phosphor Bronze | Termination Style | Cable - Crimp |
| Shield Termination | Crimp | Contact Termination | Crimp |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Center Contact Plating | Gold |
| Supplier Device Package | Straight | ||
Product Info
| Gender | Jack | Polarity | Standard |
| RF Family/Standard | BNC | ||
Environmental
| Mating Cycles | 500 | Operating Temperature | -65°C ~ 165°C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- Bulkhead Cable Jacks
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
