C016 30F006 100 12

Business

Part # Aliases	81K1496	Product Category	Circular DIN Connectors
Standard Package	50	Factory Pack Quantity	50

RoHS	RoHS Compliant	Rad Hardened	No
Approval Agency Marking	UL Recognized/CSA/VDE	Material Flammability Rating	UL94-V0

Voltage Rating	250 V	Number of Poles	6+PE
Voltage - Supply	DIN	Connector Impedance	标准
Current Rating (Max)	10 A	Current Rating - Appliance Inlet	10
Voltage - Protection Level (VP) (2416)	IP 67

Color	Black	Height	57 mm
Weight	0.04 kg	Diameter	30 mm
Packaging	Bulk	Cable Exit	Yes
Wire Gauge	20	Orientation	Keyed
Shell Style	Receptacle	Termination	Solder
Weight (g):	43.60000	Contact Form	6Signal/1Ground
Contact Type	Socket	Mounting Type	Free Hanging (In-Line), Right Angle
Angle of Throw	Right	Cable Diameter	6 mm to 12.5 mm
Cable End Type	6...12.5 mm	Connector Type	Plug, Female Sockets
Contact Finish	Silver	Fastening Type	Threaded
Mounting Style	Free Hanging	Package / Case	Plastic
Connector Style	angled	Connector Usage	Threaded
Locking Feature	threaded joint, internal thread	Contact Material	silver-plated
Housing Material	Polyamide	Length - Overall	60 mm
Package Quantity	50	Primary Material	DIN
Termination Rows	焊接	Connector - Cable	plug
Termination Style	Solder	1st Contact Gender	Socket (Female)
Color - Connectors	black	Number of Contacts	6
Dielectric Material	Polyamide	Number of Positions	7
1st Connector Gender	Female	Shell Material, Finish	Polyamide
Contact Layout, Typical	6 + 1 Ground (PE)	Contact Material - Plating	silver plated
Static Discharge Shielding	是	1st Connector Mounting Feature	6+PE

Spg	50	Type	Circular
Gender	Male	Series	eco mate
Features	Cable Clamp	Main Purpose	Cable Clamp
Manufacturer	C016 Series	Product Type	Connectors
Adapter Series	ECOMATE (C016)	Number of Units	1
Connection Method	0.75	RF Family/Standard	C016
Output Configuration	Free Hanging (In-Line), Right Angle	Application Specifics	Commercial
