C091 31K006 100 2
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | 100 2 31K006 C091 U | Product Category | Circular DIN Connectors |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | RoHS Compliant | Approval Agency Marking | UL Recognized |
| Material Flammability Rating | UL94-V0 | ||
Electrical
| Voltage Rating | 300 V | Voltage - Supply | DIN |
| Current Rating (Max) | 5 A | ||
Mechanical
| Packaging | Bulk | Cable Exit | Internal |
| Wire Gauge | 20-26 | Orientation | Keyed |
| Termination | Solder Cup | Contact Type | Pin |
| Mounting Type | Free Hanging (In-Line), Right Angle | Shell Plating | Nickel |
| Angle of Throw | Right | Cable Diameter | 4-6 mm |
| Connector Type | Plug, Male Pins | Contact Finish | Silver |
| Fastening Type | Threaded | Housing Finish | Nickel |
| Package / Case | Metal | Connector Usage | Threaded |
| Housing Material | Die Cast | Primary Material | DIN |
| Termination Style | Solder | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 6 | Dielectric Material | Thermoplastic |
| Number of Positions | 6 | Shell Size - Insert | DIN (240 Degree) |
| Shell Material, Finish | Die Cast, Nickel Plated | ||
Product Info
| Type | Cable Plug | Features | Shielded, Strain Relief |
| Manufacturer | C091-D Series | Product Type | Connectors |
| RF Family/Standard | C091D | ||
Environmental
| Seal Rating | IP 67 | Ingress Protection | IP65/67 - Dust Tight, Water Resistant, Waterproof |
| Operating Temperature | -40°C ~ 100°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- C091 A,B,D Series Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
