97-3106A-18-16S
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 10-820070-16S | Standard Package | Bulk |
Compliance
| RoHS | Contains lead / RoHS non-compliant | Tariff No | 85366910 |
| Approval Agency Marking | UL/CSA | ||
Electrical
| Voltage Rating | 3000VAC, 4200VDC | Current Rating (Max) | 23A |
Mechanical
| Weight | 0.05 | Packaging | Bulk |
| Cable Exit | Solid | Shell Size | 18 |
| Wire Gauge | 12 | Orientation | N (Normal) |
| Termination | Solder | Contact Type | Socket |
| Mounting Type | Cable Mount | Angle of Throw | Straight |
| Connector Type | Plug, Female Sockets | Contact Finish | Silver |
| Fastening Type | Threaded | Housing Finish | Olive Drab Cadmium |
| Package / Case | Metal | Connector Usage | Threaded |
| Insertion Angle | 18-16 | Housing Material | Aluminum Alloy |
| Primary Material | 5015 Commercial | Number of Contacts | 1 |
| Dielectric Material | Diallyl-Phthalate | Number of Positions | 1 |
| Shell Size - Insert | 18-16 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Layout, Typical | 1#12 | ||
Product Info
| Type | MIL-C-5015 Circular | Class | A |
| Gender | PL | Manufacturer | 97 Series |
| Application Specifics | Commercial | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 108266.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
