AD8277ARZ
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 56 |
| Standard Package Name | SOIC | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423300 |
| Rad Hardened | No | ||
Electrical
| Output | :Rail to Rail | Slew Rate | 1.1 V/µs |
| Output Type | Rail-to-Rail | Power - Input | Single/Dual |
| Settling Time | 15 us | CMRR, PSRR (Typ) | 80dB |
| Current - Output | 200µA | Current - Supply | 0.2 mA |
| Voltage - Supply | 2 V | Power Supply Type | Single|Dual |
| Number of Channels | 2 | Number of Elements | 2 |
| Resistance - Input | 0.08MΩ | Number of ADCs / DACs | :2 |
| Voltage - Input (Min) | 100µV | Gain Bandwidth Product | 550kHz |
| Rail-to-Rail Operation | No | Power Dissipation (Max) | 0.5 mW |
| Current - Output / Channel | 15mA | Voltage - Input Offset (Max) | 0.5mV |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 4mm | Height | 1.5mm |
| Length | 8.75mm | Weight | 0 |
| Bandwidth | 550 kHz | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :14 |
| Package / Case | 14SOIC N | Package Cooled | SOIC N |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | SOIC N |
| Size / Dimension | 8.75 x 4 x 1.5mm | Number of Positions | 14 |
| Supplier Device Package | 14-SOIC | ||
Product Info
| Type | Instrumentation Amplifier | Series | AD8277 |
| Base Unit | :8277 | Amplifier Type | Differential |
| Number of Circuits | 2 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- AD8276_8277.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
