ADM3053BRWZ
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Standard Package Name | SOIC W |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Standards | ISO 11898 |
| Tariff No | 85423990 | Rad Hardened | No |
Electrical
| Data Rate | 1Mbps | Interface | :CAN, Serial |
| Power - Input | Single | Voltage Rating | 4.5 V |
| Data Rate (Max) | 1 Mbps | Current - Supply | 170 mA |
| Voltage - Supply | 4.5 V | Receiver Hysteresis | 150mV |
| Voltage - Supply (Min) | 5.5 V | Voltage - Supply Span (Typ) | Not Required V |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 7.6mm | Height | 2.35mm |
| Length | 13mm | Weight | 0.01 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Number of Pins | :20 |
| Package / Case | 20SOIC W | Package Cooled | SOIC |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | SOIC W |
| Size / Dimension | 13 x 7.6 x 2.35mm | Number of Positions | 20 |
| Supplier Device Package | 20-SOIC W | ||
Product Info
| Type | Transceiver, Isolated | Duplex | Half |
| DELETED | Compliant | Protocol | CAN |
| Shutdown | Standby | Number of Transmitters | 1 |
| Number of Drivers/Receivers | 1/1 | Number of Transmitters/Receivers | 1 |
Environmental
| Operating Temperature | -40°C ~ 85°C | Operating Temperature - Junction | 85C |
Documents & Media
Sourcing & traceability
- Datasheet
- ADM3053.pdf
