ADXL203CE
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 95 |
| Standard Package Name | LCC | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| Output | :Analogue | Output Type | Analog |
| Sensitivity | 960 to 1040 mV/g | Sensor Type | :LCC |
| Sensing Angle | Dual | Voltage Rating | 3...6V |
| Current - Output | 0.7 mA | Voltage - Supply | 3 to 6 V |
| Voltage - Supply (Min) | 3 V | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Axis | Dual | Depth | 5 mm |
| Width | 5 | Height | 1.98 mm |
| Weight | 0.000074 | Bandwidth | 0.5Hz ~ 2.5kHz Selectable |
| Packaging | Tube | Lead Style | No Lead |
| Acceleration | ±1.7 g | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :8 |
| Package / Case | 8CLCC | Package Cooled | CLLCC |
| Material Finish | :- | Length - Overall | 5 mm |
| Package Quantity | CLCC | Size / Dimension | see |
| Number of Positions | 8 | Shell Size - Insert | 1.98 |
| Supplier Device Package | 8-CLCC (5x5) | ||
Product Info
| Spg | 30 | Series | ADXL203 |
| Schematic | see | Measuring Range | 1,7g |
| Number of Units | 1 | Measurement Type | :X, Y |
| RF Family/Standard | ADXL203 | Printed Circuit Board | 8 |
Environmental
| Acceleration Range | ±1.7g | Operating Temperature | -40 to 125 °C |
| Operating Temperature - Junction | 125C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ADXL103_203.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
