EVAL-ADUM4160EBZ
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Evaluation Boards | Standard Package | Boxed |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
Electrical
| Core Type | :Interface | Interface | USB |
| Voltage - Supply | 5 V, 3.3 V | Number of Elements | :ADuM4160 |
Mechanical
| Weight | 1.68 | Packaging | Bulk |
Product Info
| Type | Development Kit | Contents | Board |
| Embedded | No | Features | :Support Low and Full Speed Communications, Enumeration Control, External ESD Protection |
| Kit Type | :Interface | Technology | USB |
| Kit Contents | Evaluation Board for ADUM4160 | Main Purpose | Interface, Digital Isolator |
| Card Standard | Development Kit | Tool Type Feature | ADUM4160 |
| Primary Attributes | USB Bidirectional Isolation | Utilized IC / Part | ADuM4160 |
| Chipset Manufacturer | :Analog Devices | Secondary Attributes | 3.1 V ~ 5.5 V Supply |
| Application Specifics | :Isolator | MCU Supported Families | :ADuM3160, ADuM4160 |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Similar Parts
EVAL-CN0158-EB1Z
