TPSA226K006R0900
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 4000 | Product | Tantalum Solid Low ESR Standard Grade |
| Unit Pack | 2000 | Product Category | Tantalum Capacitors - Solid SMD |
| Standard Package | Tape & Reel, Cut Tape | Factory Pack Quantity | 2000 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85322400 |
| Automotive | NO | ||
Electrical
| ESR | 100kHz | Voltage | 6.3 Vdc |
| Tolerance | 10 % | Capacitance | 22 uF |
| Range deg/s | :AVX - TPS Series | Voltage Rating | 6.3 V |
| Voltage - Supply | 6.3V | Current - Leakage | 1.4 uA |
| Capacitance - Input | :1206 [3216 Metric] | Capacitance @ Vr, F | tantalum |
| Voltage - Supply (Min) | 6.3V | Capacitance @ Frequency | 22µF |
| Dissipation Factor (DF) | 6 | Power Dissipation (Max) | 0.06 |
| Ripple Current @ High Frequency | 0.115 mA | ESR (Equivalent Series Resistance) | 0.9 Ohm |
| Voltage - Protection Level (VP) (2416) | 8VDC | ||
Mechanical
| Depth | :1.6mm | Width | 1.6mm |
| Height | 1.6 mm | Length | 3.2mm |
| Weight | 0.00031 | Packaging | Reel |
| Termination | SMT | Construction | Flat |
| Mounting Type | Surface Mount | Reel Capacity | :2000 |
| Terminal Type | :Surface Mount (SMD, SMT) | Number of Pins | :2 |
| Package / Case | 3216-18,A | Length - Overall | 3.2 mm |
| Material - Blade | Tantalum | Package Quantity | 2000 |
| Size / Dimension | 1.6 mm W x 3.2 mm L | Tape Width - Max | :8mm |
| Termination Style | SMD/SMT | Dielectric Material | TA2O5 |
| Shell Size - Insert | 1206(3216mm) | Mounting Hole Diameter | 1206 |
Product Info
| Spg | 2000 | Style | CHIP |
| Series | TPS | Polarity | Polar |
| Matchcode | TC22U6,3VALOWR | Manufacturer | A Case |
| Measuring Range | LOWESR | Number of Units | 1 |
| Standard Leadtime | 10 weeks | Base Product Number | 3216 |
| Manufacturer Size Code | :A | ||
Environmental
| Temperature - Test | -55°C | Operating Temperature | 125 °C |
| Power Dissipation @ Temperature Rise | 6 | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- taj-ce.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
