CD1206-S01575
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Diodes | Other Names | CD1206-S01575CT |
| Product Category | Diodes - General Purpose, Power, Switching | Standard Package | Cut Tape |
| Factory Pack Quantity | 2500 | Standard Package Name | SMD |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
Electrical
| Speed | Small Signal = | Current - Test | 2.5µA @ 100V |
| Current - Surge | :4A | Voltage - Supply | 1 V |
| Current - Output 1 | :50mA | Capacitance @ Vr, F | * |
| Diode Configuration | :1206 | Voltage - Input (Min) | 1V @ 50mA |
| Power Dissipation (Max) | 400 | Voltage Regulation - Load | 100 V |
| Reverse Recovery Time (trr) | 4ns | Current - Peak Pulse (8/20us) | 4 A |
| Current - Reverse Leakage @ Vr | 2.5 uA at 75 V | Voltage - DC Reverse (Vr) (Max) | 100V |
| Current - Average Rectified (Io) | 150mA | Voltage - Reverse Standoff (Typ) | :100V |
| Current - LED Trigger (Ift) (Max) | :150mA | Current - Continuous Drain (Id) @ 25degC | 0.15 A |
Mechanical
| Weight | 0.00035 | Packaging | Tape & Reel (TR) |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :2 |
| Package / Case | 2Case 1206 | Material Finish | :MSL 1 - Unlimited |
| Package Quantity | Case 1206 | Number of Positions | 2 |
| Supplier Device Package | 1206 | ||
Product Info
| Type | Small Signal Switching Diode | Diode Type | Standard |
| Configuration | Single | RF Family/Standard | CD1206-S01575 |
Environmental
| Operating Temperature | -55 to 125 °C | Operating Temperature - Junction | -55°C ~ 125°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- CD1206_S01575.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
