XR20M1172IG28-F
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | UART Interface IC | Standard Package | 50 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Standards | IrDA|RS-232|RS-485 | Tariff No | 85423190 |
Electrical
| Data Rate | 16 Mbps | Voltage Rating | 1.62 → 3.6 V dc |
| Data Rate (Max) | 16Mbps | Current - Output | 250 uA |
| Current - Supply | 0.5 | Voltage - Supply | 1.62 V ~ 3.63 V |
| Number of Channels | 2 | Voltage - Supply (Min) | 3.63 |
| With IrDA Encoder/Decoder | Yes | ||
Mechanical
| Width | 4.5mm | Height | 1.05mm |
| Length | 9.8mm | Weight | 0.000426 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :28 | Package / Case | 28-TSSOP (0.173", 4.40mm Width) |
| Package Cooled | TSSOP | Material Finish | :MSL 1 - Unlimited |
| Package Quantity | TSSOP | Size / Dimension | 9.8 x 4.5 x 1.05mm |
| Number of Positions | 28 | Supplier Device Package | 28-TSSOP |
Product Info
| FIFO's | Yes | Protocol | RS485 |
| With Modem Control | Yes | With Auto Flow Control | Yes |
| Compatible Sensor Size (Max) | Yes | With False Start Bit Detection | Yes |
Environmental
| Operating Temperature | +85 °C | ||
Documents & Media
PDF Document
Online Document
Online Document
PDF Document
Online Document
Sourcing & traceability
- Datasheet
- Datasheet Update 18/Oct/2013
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
