09032646861
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | 03 09 09-03-264-6861 264 6861 | Standard Package | 1 |
| Factory Pack Quantity | 20 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Contact Resistance | 20mΩ | Current Rating (Max) | 2A |
Mechanical
| Depth | 10.6 | Pitch | 0.100" (2.54mm) |
| Height | 11.6 | Packaging | Bulk |
| Orientation | 直 | Termination | Press Fit |
| Length - Tail | 13.2 mm | Mounting Type | Straight |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Gold Over Nickel |
| Number of Rows | 2 | Contact Material | Copper Alloy |
| Housing Material | Thermoplastic | Length - Overall | 95 |
| Termination Rows | a/c | Termination Style | Press Fit |
| Number of Contacts | 64 | Number of Positions | 96 |
| Material - Insulation | Thermoplastic, Glass Filled | ||
Product Info
| Type | Backplane | Style | C |
| Gender | F | Series | 09 03 |
| Class Code | C2 | CAD Drawing | 3D CAD Model |
| Product Type | Receptacles | Outlet Types and Quantity | A/c |
| Number of Positions Loaded | 64 | ||
Environmental
| Ratings | C2 | Level, Class | 2 |
| Operating Temperature | +125°C | ||
