Part # Aliases	06 09 09-06-132-6901 132 6901	Product Category	DIN 41612 Connectors
Standard Package	1	Factory Pack Quantity	20

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85366910
Material Flammability Rating	UL94 V-0

Depth	22	Pitch	0.200" (5.08mm)
Height	14.7	Weight	0.018
Packaging	Bulk	Orientation	angled 90°
Termination	Solder	Lead Spacing	len. 3mm
Length - Tail	3 mm	Mounting Type	Right Angle
Connector Type	Header, Male Pins	Contact Finish	Gold Over Nickel
Number of Rows	2	Contact Material	Copper Alloy
Housing Material	Thermoplastic	Length - Overall	93.9
Package Quantity	20	Connector - Cable	socket
Termination Style	Solder Pin	Number of Contacts	32
Contact Termination	:Through Hole Right Angle	Number of Positions	48 (Power)
Material - Insulation	Thermoplastic, Glass Filled	Contact Finish Thickness	Flash
Contact Material - Plating	gold plated	Material - Housing & Prism	thermoplastic
1st Connector Mounting Feature	b+z

Level, Class	2	Mating Cycles	:400
Mechanical Life	400cycles	Operating Temperature	-55...125°C
