点击放大查看
15110262601000
| Manufacturer | |
| Description | CONN HEADER 26POS 1.27MM SMD Harting Har-Flex Series 1.27mm Pitch 26 Way 2 Row Straight PCB Header, Solder Termination Board to Board & Mezzanine Connectors HAR-FLEX STRT MALE 26P 1.75MM HGT PL1 har-flexstrtmale1.75mm26pPL1 Harting Har-Flex 系列 1.27mm节距 26路 (2排) 直 PCB 针座, 焊接端接 , 表面安装 |
| Category |
商业参数
| 其他名称 | 1195-3362-2 | 零件号别名 | 015110 015110-26-260-1000 1000 26 260 |
| 标准包装数量 | 280 | 工厂包装数量 | 1 |
合规参数
| RoHS | Lead free / RoHS Compliant | ||
机械参数
| 颜色 | Black | 间距 | 0.050" (1.27mm) |
| 包装方式 | Tape & Reel (TR) | 方向 | 直 |
| 排间距 | 0.050" (1.27mm) | 端接方式 | Solder |
| 触头类型 | Male Pin | 安装类型 | Surface Mount |
| 连接器类型 | Header, Shrouded | 排数 | 2 |
| 堆叠方法 | 1.75 mm | 触头材料 | Copper Alloy |
| 端接排数 | 焊接 | 端接样式 | SMD |
| 触点数 | 26 | 位数 | 26 |
| 接触长度 - 配合 | 0.157" (4.00mm) | ||
产品信息
| 类型 | Board to Board | 系列 | Har-Flex |
| 覆盖范围 | 覆盖 | 产品特性 | Board Guide, Solder Retention |
| 产品子类型 | Headers | 加载位置数 | All |
