M20-1060200
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | ||
Electrical
| Range deg/s | :HARWIN - M20-1 Series | Voltage Rating | :250V |
| Contact Resistance | :20mohm | Current Rating (Max) | :3A |
| Insulation Resistance | :5000Mohm | ||
Mechanical
| Depth | 14mm | Pitch | 2.54mm |
| Width | 2.54mm | Length | 5.28mm |
| Weight | 0.01 | Mounting Type | Straight |
| Contact Finish | :- | Mounting Style | Wire |
| Number of Rows | 1 | Contact Material | :- |
| Housing Material | PPO | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 2 |
| Contact Termination | :Crimp | Number of Positions | :2 |
| Material - Insulation | :PBT (Polybutylene Terephthalate), Glass Filled | ||
Product Info
| Gender | Female | Series | M20-10 |
| CAD Drawing | 3D CAD Model | Product Type | Receptacles / Sockets - Housings |
| For Use With/Related Products | M20 Series Connector | ||
Environmental
| Operating Temperature | :105°C | ||
