0438600001
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 20 Days | Subcategory | Connector Telephone and Telecom |
| Standard Package | Rail / Tube | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | :125V | Contact Resistance | 20 mohm |
| Dielectric Strength | :1000V | Voltage - Breakdown | :1000V |
| Current Rating (Max) | 1.5/Contact A | Insulation Resistance | :500Mohm |
| Voltage - Input (Min) | 125V | Voltage - Supply (Min) | 125V |
| Connector - Voltage Input | :Cat3 | ||
Mechanical
| Depth | 14.99 mm | Pitch | 2.04 mm |
| Width | :15.75mm | Height | 13.21 mm |
| Length | :13.21mm | Weight | 0.000215 |
| Material | :PA Polyamide (Nylon), High Temperature, Glass-filled | LED Color | Does Not Contain LED |
| Packaging | Tube | Shielding | Unshielded |
| Orientation | 90° Angle (Right) | Termination | Solder |
| Housing Color | Black | Mounting Type | Through Hole |
| Tab Direction | Up | Connector Type | Jack |
| Contact Finish | Gold Over Nickel | Mounting Style | Through Hole |
| Number of Rows | 1 | Contact Material | Phosphor Bronze |
| Housing Material | Polyamide | Length - Overall | 15.75 mm |
| Color - Connectors | :Black | Number of Contacts | 8 |
| Contact Termination | :Through Hole Right Angle | Number of Positions | :8 |
| Contact Finish Thickness | 50µin (1.27µm) | Material - Housing & Prism | :PA Polyamide (Nylon) |
Product Info
| Type | RJ-45 | Gender | F |
| Series | :43860 | Features | Board Lock |
| Category Number | Cat 3 | Number of Ports | 1 |
| Industry Aliases | 43860-0001, 438600001 | RF Family/Standard | 43860 |
| Number of Positions Loaded | 8 | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Ratings | Cat3 | Mating Cycles | :500 |
| Operating Temperature | -40°C ~ 85°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- 0438600001_MODULAR_JACKS_PLUG.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
