1861675
| Manufacturer | |
| Description | Pluggable Terminal Blocks MCO 1.5/ 5-GR-3.81 Conn Shrouded Header HDR 5 POS 3.81mm Solder RA Thru-Hole TERM BLOCK HDR 5POS R/A 3.81MM Header for PCB plug connector MCO 1,5/ 5-GR-3,81 MCO15/5-GR-381 Phoenix Contact COMBICON MCO 系列 5路 3.81mm节距 PCB 接线端子块 , 焊接端接 |
| Category |
商业参数
| 产品 | Headers | 商标名 | COMBICON Control |
| 产品类别 | Pluggable Terminal Blocks | 标准包装数量 | 50 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 电流 | 8A | 电压 | 300V |
| 额定电压 | 125 V | 最大额定电流 | 8 A |
| 最小输入电压 | 160V | ||
机械参数
| 颜色 | Green | 深度 | 7.25 |
| 间距 | 0.150" (3.81mm) | 重量 | 0.095592 oz |
| 包装方式 | Bulk | 端接方式 | Solder |
| 外壳颜色 | Green | 安装类型 | Through Hole |
| 接触镀层 | Tin | 排数 | 1 |
| 触头材料 | 锡 | 壳体材料 | Polybutylene Terephthalate |
| 总长度 | 20.44 | 端接排数 | 焊接 |
| 端接样式 | Through Hole | 排针方向 | 90°, Right Angle, Vertical |
| 触点数 | 5 | 位数 | 5 |
| 接线端子类型 | Header, Male Pins, Shrouded (2 Side) | ||
产品信息
| 类型 | Shrouded Header | 连接器性别 | HDR |
| 系列 | MCO | 层数 | 1 |
| 每层位数 | 5 | ||
