点击放大查看
2966595
| Manufacturer | |
| Description | Solid State Relays - Industrial Mount OPT-24DC/24DC/2 OptoCoupler Transistor-OUT 1-CH 4-Pin SIP PLUGGABLE MINI OPTOCOUPLER 24VDC MINIATURE OPTOCOUPLE 24VD Optocoupler;Industrial;Rectangular;Transistor;Pluggableminiature Phoenix Contact 光耦合器 |
| Category |
Business
| Lead Time | 28 Days | Tradename | INTERFACE Relay |
| Subcategory | OptoCoupler | Product Category | Solid State Relays - Industrial Mount |
| Standard Package | 10 | Factory Pack Quantity | 10 |
| Standard Package Name | SIP | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Output | Phototransistor | Circuit | SPST-NO (1 Form A) |
| Input Type | LED | Output Type | DC |
| Load Current | 3A | Voltage - Load | 3 ~ 33 V |
| Voltage Rating | 24 | Voltage - Supply | 24 VDC |
| Number of Channels | 1 | Current Rating (Max) | 3 A |
| Voltage - Input (Min) | 24VDC | Voltage - Supply (Min) | 3 VDC to 33 VDC |
Mechanical
| Width | 5 | Weight | 0.184130 oz |
| Packaging | Bulk | Lead Style | Through Hole |
| Contact Form | 1 Form A (SPST-NO) | Mounting Type | Through Hole |
| Mounting Style | Plug In | Number of Pins | 4 |
| Package / Case | 4-SIP | Package Cooled | SIP |
| Length - Overall | 28 | Package Quantity | SIP |
| Termination Style | Plug In | Number of Positions | 4 |
| Shell Size - Insert | 15 | ||
Product Info
| Type | Industrial | Series | OPT |
| Function | Y | Relay Type | Relay |
| Product Type | Industrial Mount | Industry Aliases | OPT-24DC/24DC/2 |
| Base Product Number | OPT-24DC/24DC/2 | Printed Circuit Board | 4 |
Environmental
| Operating Temperature | + 60 C | ||
