Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 90261089 |
Electrical
| Output | :I2C digital, PWM and SDM/analog Volt interface | Accuracy | ±1.8%RH |
| Interface | Serial-I2C | Tolerance | ±0,2% |
| Resolution | 12 bit | Output Type | Digital |
| Sensitivity | :± 1% | Sensor Type | :Digital |
| Response Time | :8s | Voltage Rating | 2.1 V |
| Current - Output | :300µA | Voltage - Supply | :2.1VDC |
| Voltage - Supply (Min) | 3.6 V | Voltage - Supply (Vcc/Vdd) | :2.1V DC to 3.6V DC |
Mechanical
| Width | 3mm | Height | 1.1mm |
| Length | 3mm | Weight | 0.000025 |
| Mounting Type | Surface Mount | Connector Type | :SMD |
| Number of Pins | :6 | Package / Case | DFN6 |
| Package Cooled | DFN | Material Finish | :- |
| Package Quantity | 10 | Size / Dimension | 3 x 3 x 1.1mm |
| Number of Positions | 6 | ||
Product Info
| Spg | 10 | Schematic | see |
| Measuring Range | 0...100% RH | Number of Units | 1 |
| Associated Items | SENSIRION-SF2 | ||
Environmental
| Humidity Range | :0% to 100% Relative Humidity | Operating Temperature | +125 °C |
