HK10052N2S-T
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 587-1503-1 | Standard Package | Tape & Reel |
Compliance
| RoHS | Lead free / RoHS Compliant | Rad Hardened | No |
| Military Standard | Not Required | ||
Electrical
| Q @ Freq | 8@100MHz | Qmax @ Th | 8 |
| Tolerance | 0.3 nH | Inductance | 2.2 nH |
| Test Frequency | 100MHz | DC Resistance (DCR) | 130 mOhm Max |
| Current Rating (Max) | 700 mA | Frequency - Self Resonant | 6GHz |
| Current - DC Forward (If) (Max) | 700 mA | Resistance - Initial (Ri) (Min) | 130 mOhm |
Mechanical
| Depth | 0.55 mm | Width | 0.5 mm |
| Height | 0.55 mm | Diameter | Not Required mm |
| Packaging | Tape & Reel (TR) | Shielding | Unshielded |
| Core Material | Ceramic | Mounting Type | Surface Mount |
| Package / Case | 0402 | Length - Overall | 1.05 mm |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | Termination Style | SMD/SMT |
| Height - Seated (Max) | 0.022" (0.55mm) | Supplier Device Package | 0402 (1005 Metric) |
Product Info
| Type | High Frequency Chip | Technology | Multi-Layer |
| Failure Rate | Not Required | ||
Environmental
| Operating Temperature | -55°C ~ 85°C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
Online Document
PDF Document
Sourcing & traceability
- Datasheet
- HK10052N2S-T.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
