Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | :UL94V-1 | ||
Electrical
| Range deg/s | :TE - AMPMODU Mod II Series | Switch Function | Detent Latching |
| Connector - Voltage Input | w/o terminals | ||
Mechanical
| Color | Black | Depth | 4.8mm |
| Pitch | 0.100" (2.54mm) | Width | 13.7mm |
| Height | 13.7 mm | Length | 22.3mm |
| Weight | 0.07 | Material | :Thermoplastic (PPO) |
| Packaging | Bulk | Row Spacing | 2.54 mm |
| Termination | :Crimp | Pitch - Post | 2.54mm |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Receptacle | Contact Finish | :- |
| Fastening Type | Locking Ramp | Mounting Style | for cable |
| Number of Rows | 1 | Contact Material | :- |
| Housing Material | Thermoplastic | Length - Overall | 22.3 mm |
| Package Quantity | 1 | Connector - Cable | plug |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Color - Connectors | :Black | Number of Contacts | 8 |
| Contact Termination | Crimp | Number of Positions | 8 |
| 1st Connector Mounting Type | :PC Board | 1st Connector Mounting Feature | 1x8 |
Product Info
| Spg | 1 | Note | Contacts Not Provided |
| Type | Housing | Gender | Female |
| Series | AMPMODU | Product Type | Receptacles / Sockets - Housings |
| Adapter Series | AMPMODU MOD II | Number of Units | 1 |
| For Use With/Related Products | Centerline Mod II Connector | ||
Environmental
| Operating Temperature | :+80°C | ||
