826629-8

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Range deg/s

:TE - AMPMODU Mod II Series

Current Rating (Max)

Color	Green	Depth	2.5 mm
Pitch	2.54 mm	Height	9.5 mm
Weight	0.053	Packaging	Bulk
Orientation	straight	Row Spacing	2.54 mm
Termination	Solder	Contact Type	Male Pin
Lead Spacing	:2.54mm	Pitch - Post	2.54 [.100]
1st Connector	No	2nd Connector	Without
Housing Color	Green	Mounting Type	Vertical
Connector Type	Breakaway	Contact Finish	Gold Over Nickel
Mounting Style	Through Hole	Number of Rows	1
Profile (W x H)	Standard	Contact Material	Phosphor Bronze
Housing Material	Thermoplastic Polyester	Length - Overall	20.32 mm
Mounting Feature	Without	Package Quantity	500
Panel Mount Type	Without	Connector - Cable	pin header
Termination Style	Through Hole	1st Contact Gender	Pin (Male)
Number of Contacts	8	Contact Termination	:Through Hole Vertical
Number of Positions	8	Length - Post (Mating)	6.7 mm
Contact Length - Mating	6.70 [0.264]	Surface Mount Land Size	No
Termination Post Length	3.20 [0.126]	Contact Finish Thickness	31.5µin (0.80µm)
Exterior Housing Material	:Green, glass filled polyester	Contact Material - Plating	gold plated
1st Connector Mounting Feature	1x8
