Product Category	Pin & Socket Connectors	Standard Package	Bulk
Factory Pack Quantity	1000

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant

Contact Resistance	10mΩ	Current Rating (Max)	4 A
Voltage - Supply (Min)	250VAC

Depth	2.67 mm	Pitch	Not Required mm
Weight	0.001	Packaging	Bulk
Wire Gauge	0.12-0.4Â² [26-22]	Termination	Crimp
Contact Size	:22	Contact Type	Signal
Housing Color	Not Required	Mounting Type	Straight
Pin or Socket	Socket	Connector Type	Connector Headers and PCB Receptacles
Contact Finish	Pre-Tin	Mounting Style	Cable
Contact Material	Phosphor Bronze	Housing Material	Not Required
Length - Overall	11.18 mm	Package Quantity	Loose Piece
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Number of Contacts	Not Required	Contact Termination	Crimp
Insulation Diameter	0.89 â 1.65 [0.035 â 0.065]	Wire Gauge or Range - AWG	:26AWG
Wire Gauge or Range - mm2	:0.4mm²	Diameter - Outside, Non-Expanded	:1.65mm

Note	Not for use in housing Part No. 770602.	Type	Contact
Gender	SKT	Series	MTA-100
CAD Drawing	3D CAD Model	Product Type	CST-100 II Contacts
For Use With/Related Products	CST-100 II Housings

1445336-1
