2-1375820-0

Name: 2-1375820-0
SKU: 2-1375820-0
Price: 0.783 USD
Availability: InStock

Business

Product Category

Headers & Wire Housings

Standard Package

Bulk

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Leadfree Defin	Not relevant for lead free process	UL File Number	E28476
Approval Agency	CSA,UL	CSA File Number	LR 7189
Standard Number	CSA, UL	RoHSELV Compliance	RoHS compliant, ELV compliant
Approval Agency Marking	已认证	Material Flammability Rating	UL 94V-0

Voltage - Supply	250 VAC	Connector Impedance	压接
Current Rating (Max)	7

Color	White	Pitch	2.54 mm
Height	6.6 mm [ .26 in ]	Length	51.31 mm [ 2.02 in ]
Lock Type	不带	Packaging	Bulk
Shrouding	No	Body Color	自然
Cable Exit	180Â°	Wire Gauge	22-28 AWG
Contact Type	Female Socket	2nd Connector	With
Housing Color	White	Mounting Type	Straight
Angle of Throw	Straight	Connector Type	Crimp
Contact Finish	2.54 [0.100]	Fastening Type	Locking Ramp
Mounting Style	不带	Number of Rows	1
Connector Usage	Receptacle	Housing Material	Polymer
Length - Overall	2.02"	Mounting Feature	Without
Package Quantity	1	Panel Mount Type	Without
Primary Material	InterconnectSystem	Pin Hole Diameter	0.1"
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Mating Orientation	With	Number of Contacts	20
Termination Finish	不带	Contact Termination	Crimp
Number of Positions	20	Compatible Shell Size	配合指定的 MTA .100 接头、类似竞争性带缺口接头和 CST .100 带罩接头
Mounting Hole Diameter	带有	Contact Layout, Typical	同轴
Static Discharge Shielding	不带

Note	Not interchangeable with CST-100 contacts and housings.; Mates with all MTA-100	Type	Housing
Gender	RCP	Series	CST-100
Sealable	否	Manufacturer	AMP
Product Type	CST-100 II Housings	Application Specifics	Wire-to-Board
