点击放大查看
204370-2
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | M39029 M39029/58-360 | Product Category | D-Sub Contacts |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant By Exemption | Tariff No | 85369010 |
| Rad Hardened | No | Qualification | No |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant / ELV compliant |
| Approval Agency Marking | Yes | ||
Electrical
| Current - Output High, Low | No | ||
Mechanical
| Depth | 1.57 mm | Pitch | Not Required mm |
| Length | 13.49mm | Weight | 0.002 |
| Diameter | 0.76 | Packaging | Bulk |
| Wire Gauge | 28-22 | Contact End | Orange, blue, black |
| Termination | Crimp | Contact Form | Machined |
| Contact Size | 22 | Contact Type | Signal |
| Mounting Type | Straight | Connector Type | Connector D-Subminiature |
| Contact Finish | Gold Over Nickel | Mounting Style | Cable |
| Contact Material | Copper Alloy | Housing Material | Not Required |
| Package Quantity | Loose Piece | Primary Material | Copper Alloy |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Number of Contacts | Not Required | Contact Tail Length | 22 |
| Contact Termination | Crimp | Insulation Diameter | 1.38 [.054] Max. |
| Contact Material - Mating | Gold | Wire Gauge or Range - AWG | 0.08-0.40² [28-22] |
| Contact Material - Plating | Gold | ||
Product Info
| Note | Color bands are read in the direction of terminal (wire barrel) end to mating en | Type | Signal |
| Gender | PIN | Series | 90 |
| Manufacturer | AMP | Product Type | Contact |
| Number of Ports | 1 Port | Other Specifications | Wire/Cable |
| Equipment Part Numbers | M39029/58-360 | For Use With/Related Products | :AMPLIMITE 90 Series Connectors |
Similar Parts
204509-7
te connectivity / amp
$202.6400
Details
1757823-1
te connectivity / amp
$92.3134
Details
91067-1
te connectivity / amp
$89.5220
Details
445011-2
te connectivity / amp
$514.3384
Details
212933-3
te connectivity / amp
$809.8800
Details
445011-1
te connectivity / amp
$529.9750
Details
204501-6
te connectivity / amp
$29.8384
Details
204503-4
te connectivity / amp
$36.5500
Details
204505-5
te connectivity / amp
$47.8516
Details
204370-2
te connectivity / amp
$2.7924
Details
445012-1
te connectivity / amp
$858.7516
Details
204503-5
te connectivity / amp
$81.1417
Details
204505-6
te connectivity / amp
$47.0016
Details
204507-5
te connectivity / amp
$58.0516
Details
204507-6
te connectivity / amp
$59.7516
Details
1-206063-3
te connectivity / amp
$440.8984
Details
1883448-1
te connectivity / amp
$1008.5944
Details
601966-6
