3-350820-2

Business

Product	Faston Terminals	Product Category	Terminals
Standard Package	Bulk	Factory Pack Quantity	1000

RoHS	RoHS Compliant	Standards	RoHSCompliant,ELVCompliant
Tariff No	85369010	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	Approval Agency	:CSA, UL, VDE
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-2

Color	Blue	Depth	10.38 mm
Width	6.3mm	Finish	Tin
Length	0.855in	Weight	0.097
Material	Brass	Packaging	Bulk
Tab Width	5.16 mm²	Thickness	0.8mm
Insulation	Insulated	Wire Gauge	14-16 AWG
Orientation	straight	Termination	Crimp
Body Material	Brass	Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	0.25 in x 0.032 in	Tab Thickness	0.032" (0.81mm)
Terminal Type	Standard	Angle of Throw	Straight
Connector Type	Quick Disconnect Terminal	Contact Finish	Tin
Mounting Style	for cable	Plating - Body	Tin
Connector Style	Straight	Width - Overall	0.409"
Contact Material	Brass	Ferrule Material	insulated
Housing Material	Nylon	Insulation Color	:Blue
Length - Overall	0.855" (21.72mm)	Package Quantity	Loose Piece
Primary Material	QuickDisconnect	Insulation Height	Non-Insulation Support
Color - Connectors	:Blue	Insulation Diameter	4.06 [.160] Max.
Insulation Material	Nylon	Material - Insulation	Yes
Wire Gauge or Range - AWG	:16AWG	Wire Gauge or Range - mm2	1.25-2.00Â² [16-14]
Contact Material - Plating	tinned	Diameter - Outside, Non-Expanded	:4.06mm
