Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	20

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Leadfree Defin	Not relevant for lead free process	UL File Number	E28476
CSA File Number	LR7189	Standard Number	CSA, UL
CSA Certification	Certified	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-2

Color	White	Pitch	2.54 mm
Height	7.75 mm [ .305 in ]	Length	17.78 mm [ .7 in ]
Packaging	Bulk	Shrouding	No
Wire Type	Discrete or Ribbon Cable	Body Color	白色
Cable Exit	90Â°	Cable Type	分离式导线, 绞线
Wire Gauge	24 AWG	Termination	IDT
Contact Type	Female Socket	Polarization	Polarizing Tab
2nd Connector	With	Contact Shape	Square
Housing Color	White	Mounting Type	Free Hanging (In-Line)
Connector Type	Feed Thru	Contact Finish	Tin Over Nickel
Contact Timing	Without	Fastening Type	Locking Ramp
Mounting Style	Wire	Number of Rows	1
Plating - Body	Nickel	Shell Material	标准
Connector Usage	Receptacle	Insert Material	铜合金
Contact Material	Copper Alloy	Housing Material	Nylon
Mounting Feature	Without	Package Quantity	Loose Piece
Panel Mount Type	Without	Cable Termination	IDC
Termination Style	IDC	1st Contact Gender	Socket (Female)
Mating Orientation	With	Number of Contacts	7
Termination Finish	带有	Contact Termination	Locking Lance
Insulation Diameter	1.52 mm [ .06 in ]	Number of Positions	7
Compatible Shell Size	MTA .100 头	Contact Length - Post	电源
Mounting Hole Diameter	带有	Contact Finish - Mating	锡
Contact Layout, Typical	2.54 [0.100]	Contact Finish Thickness	80µin (2.03µm)
Small Diameter Recovered	No	Wire Gauge or Range - mm2	0.2Â² [24]
Static Discharge Shielding	带有	Jacket (Insulation) Thickness	.762 µm, 30 µin

3-644563-7
