Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | RoHSCompliant,ELVCompliant |
| Tariff No | 85366910 | Leadfree Defin | Not relevant for lead free process |
| Approval Agency | CSA,UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Number of Outputs | 9 | Current Rating (Max) | 13 A |
| Voltage - Supply (Min) | 250VAC | Connector - Voltage Input | Commercial Pin and Socket |
Mechanical
| Color | Natural | Depth | 25.4 mm |
| Pitch | 5.03 mm | Height | 16.89 mm |
| Length | 1in | Weight | 0.005 |
| Lock Type | Detent Lock | Packaging | Bulk |
| Row Spacing | 0.198" (5.03mm) | Contact Type | Male or Female |
| Body Material | :Nylon | Core Diameter | 0.093in. |
| Housing Color | Natural | Mounting Type | Straight |
| Angle of Throw | Straight | Connector Type | Receptacle |
| Fastening Type | Locking Ramp | Mounting Style | FreeHanging |
| Number of Rows | 3 | Housing Material | Nylon |
| Length - Overall | 5.03 [0.198] | Package Quantity | One Piece Housing |
| Primary Material | InterconnectSystem | Pin Hole Diameter | 0.198" |
| Number of Contacts | 9 | Contact Termination | Crimp |
| Number of Positions | 9 | Contact Layout, Typical | Matrix |
| Contact Finish Thickness | 2.36 [0.093] | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | Soft Shell |
| Features | FreeHanging | Manufacturer | SoftShell |
| Product Type | Housing | Number of Circuits | 9 |
| Matrix (Columns x Rows) | 0.198in. | For Use With/Related Products | :.093" Commercial Pin and Socket Connectors |
Environmental
| Operating Temperature | +25to+65°C | ||
